G series Gas pressure Horizontal type Sintering Furnace
G series Gas pressure Horizontal type Sintering Furnace
Haoyue gas pressure sintering furnaces provide high-temperature pressure sintering for silicon nitride, ceramics and advanced materials requiring stable atmosphere control.
Key Features
Technical Highlights
The horizontal furnace structure, pressure control and high-temperature performance help improve material density, strength and process repeatability for demanding ceramic and industrial applications.
Good Temperature Uniformity / Fast Heating Rate / Good Safety Performance /Controllable Organizational Structure
Horizontal design makes loading, unloading, and maintenance work more convenient. Automatic control of the entire process;
Good temperature uniformity: Adopting a special furnace liner structure and heater layout, the furnace temperature uniformity is good;
Selection guide
Confirm the process window before quotation.
For faster engineering review, prepare the core process boundaries before sending an inquiry.
Can the chamber be customized?
Yes. Chamber size, heating zone, fixture, pressure, and atmosphere configuration should be confirmed through technical review.
Is a process test recommended?
For new materials or demanding density targets, a sample process discussion helps reduce equipment selection risk.
What should be sent with an inquiry?
Material, target temperature, pressure or load, atmosphere, workpiece size, and expected capacity are the most useful inputs.
Official Specification Tables
Imported from Haoyue's official product data and reorganized for clearer technical review.
| No. | Model | Heater | Structure | Loading | Chamber Size (mm) | Gas Pressure (MPa) | Ultimate Vaccum (Pa) | Operating temperature (°C) |
|---|---|---|---|---|---|---|---|---|
| G4HGR20 | PHSgr-40/40/120-2000 | GR | Horizontal | Side Loading | 400*400*1200 | 6/10 | 10Pa | 2000 |
| G5HGR20 | PHSgr-50/50/180-2000 | GR | Horizontal | Side Loading | 500*500*1800 | 6/10 | 10Pa | 2000 |
Typical Applications
